AGM ASP-MICRO

Name: AGM ASP-MICRO
Brand: AGM
SKU: 3093251001AM16
Price: 499.0000 USD
Availability: InStock
Rating: 3 (4 reviews)

Digital Day & Night Optics

PART #3093251001AM16

4 reviews | Write a review

Description And features

The PRG Defense ASP represents the line of the most technologically advanced thermal imaging monoculars currently existing on the market. Based on Shutterless microbolometer cores and made of high-grade aircraft aluminum alloy the unit guarantees durability and outstanding performance even to the most sophisticated users. This uncooled, long-wave infrared, magnified thermal imaging camera by PRG Defense is designed for fulfilling of both, day and night missions, irrespective of the environment and weather factors. Variety of objective lenses (25 mm, 50 mm, 75 mm, and 100 mm) enables the operator to use the device as both a compact, pocket-sized thermal imaging monocular, or as a long-range observation tool. The ASP thermal imaging monocular can be easily connected to extended battery pack to increase operational time. Optional Wi-Fi module for live video streaming and recording is also available.

Quick conversion of daytime optics into thermal imaging scope
Mounts in front of any daytime scope, no re-zeroing is required
FLIR Tau 2 17μm pitch thermal sensor
Lightweight and robust design
Easy to operate device
Manually adjustable objective lens
Real-time display
Multiple color palettes
Wireless remote control
Waterproof
External Wi-Fi module
Integral MIL-STD-1913 rails for optional accessories
Powered by two standard CR123A batteries
External power supply via micro USB
Limited 3-Year Warranty

Characteristics

Detector type: FLIR Tau 2 17μm Uncooled Microbolometer

Refresh rate: 30 Hz

Resolution: 336x256

FOV: 7.8° x 5.9°

Package Includes

Two Lithium CR123A batteries
Remote Control

Downloads

Data Sheet

User Manual

Quick Guide

Export Restrictions:

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.

$499.00

Compare

Quick Order

Add to cart

Specifications

FOV (angular)

attr2

Diopter Adjustment

attr1

Body Housing Material

attr3

Firmware update

FIRMWARE UPDATE INSTRUCTION

Please read the instructions below before updating the firmware.

Check current firmware version of your device, for this go to your device’s main menu to option “Info” or “Version” and check what number you have. Compare the number with the latest version of the firmware on the AGM website.

Download the firmware update package to your PC and unzip it.

NOTE: Do not open the DAV or BIN file on your computer as it may corrupt the file.

Connect the thermal device to your PC with USB cable.
Turn on the thermal device.
Disable the Wi-Fi Hotspot function in the device menu if WiFi is enabled.
Open the detected disk (USB drive) in file manager program. Copy the unzipped .dav file and paste it to the root directory of the device.
Turn off the device.
Turn on the device. After a while, the firmware update process will start automatically. During the update, the screen will display the inscription "Upgrading ...". The update process will be completed when the inscription "Upgrading ..." goes out. Repeat steps 4-6 for each updating file.
Turn off the device and disconnect it from your PC.

WARNING:
If your device does not have a built-in rechargeable battery and is powered by replaceable Lithium batteries, remove the batteries from the battery compartment before connecting the device to your PC, or it may cause computer damage.

If you removed the batteries, please make sure the device is connected to the computer during the update process. Otherwise, the device will shut off and may cause unnecessary upgrade failure, firmware damage, etc.

To begin the procedure for updating the firmware of your equipment, you must confirm that you are familiar with and agree to the "AGM GLOBAL VISION" Export Policy («AGM GLOBAL VISION» Export Policy). By continuing the process of updating your device, you are confirming that you received this device legally and in compliance with all applicable US export laws and that you are not on the Banned Persons List and/or are not affiliated with any of the Banned Persons as defined by the US Government.
If these conditions are met, please check the box on the left and follow the instructions for updating the hardware firmware.

Please check the latest firmware. Click the FW Version to download the firmware update package.

ASP-MICRO TM160 THERMAL MONOCULAR FIRMWARE

Firmware Versions:
- V5.5.37_220112
  - Updated FPGA FW
  - Improve image quality.
  - Support "Auto Power Off."
  - Support "Time Sync."
  - Support "Burn-Prevention."
- V5.4.24_210927
  - Repacked firmware. All the features keep the same.
- V5.4.24_200808
  - Basic version.
ASP-MICRO TM384 THERMAL MONOCULAR FIRMWARE

Firmware Versions:
- V5.5.37_220112
  - Support "Auto Power Off."
  - Support "Time Sync."
  - Support "Burn-Prevention."
- V5.4.24_210927
  - Repacked firmware. All the features keep the same.
- V5.4.24_200808
  - Basic version.
ASP TM25-384/TM35-384 THERMAL MONOCULAR FIRMWARE

Firmware Versions:
- V5.4.12_190709
  - Basic version.
ASP TM25-384/TM35-384 THERMAL MONOCULAR FIRMWARE

Firmware Versions:
- V5.4.12_190709
  - Basic version.
ASP TM35-640 THERMAL MONOCULAR FIRMWARE

Firmware Versions:
- V5.4.24_210927
  - Repacked firmware. All the features keep the same.
- V5.5.37_220112
  - Support "Auto Power Off."
  - Support "Time Sync."
  - Support "Burn-Prevention."
- V5.4.24_200808
  - Basic version.
TAIPAN-384 THERMAL MONOCULAR SERIES FIRMWARE

Firmware Versions:
- V5.5.21_220127
  - Support "Auto Power Off."
  - Support "Time Sync."
  - Support "Burn-Prevention."
- V5.4.26_210827
  - Repacked firmware. All the features keep the same.
- V5.4.26_201120
  - Basic version.
EXPLORATOR FSB50-640 THERMAL BINOCULAR FIRMWARE

Firmware Versions:
- V5.4.14_191126
  - Basic version.
FUZION 384 FUSION MONOCULARES SERIES FIRMWARE

Firmware Versions:
FUZION 640 FUSION MONOCULARES SERIES FIRMWARE

Firmware Versions:
